VMC855 Box guideway Belt spindle
- Model
- VMC855
Item specifics
- brand
- zopocnc
- cnc
- FANUC/SIEMENS/MITSUBISHI
- spindle
- belt spindle
- control
- semi-closed loop control
Review
Description
VMC855
Classic model
The best choice for aluminum processing, high-precision molds and parts processing
850/550/650mm
X/Y/Z axis travel
550×1000mm
Worktable size
8000rpm
Spindle speed
12/12/12m/min
Rapid feed speed
- Model
- Appearance
- Charasteristics
- Parameters
- Contact Us
Appearance
Charasteristics
High rigidity, high efficiency and high stability structural design
Hot sale 10000+ units Excellent overall performance, high cost performance
- The unique arc-shaped base design after finite element analysis and the internal reinforcement rib layout provide better processing rigidity among machine tools of the same size.
- The base adopts a large-span structure with two 45mm roller linear guideways, which provides the machine with very strong load-bearing capacity while meeting the high rigidity requirements during heavy cutting.
High performance spindle
- The spindle box guideway is designed with a large cross-section and the structure is optimized to be the best among similar models. It is equipped with a Z-axis weightless structure to ensure the stability and accuracy of vertical high-speed positioning.
- The Z-axis guideway span is larger than that of traditional models, which greatly improves the contact ratio between the spindle box and the column, ensuring high torque of the spindle during processing.
- The short nose spindle ensures the cutting rigidity of the machine.
Superior processing capabilities
The VMC series machine tools with stable cutting performance are suitable for automotive parts, 3C industry, military industry, molds, sewing equipment and diversified product processing applications in the ever-changing market.
Parameters
Working range
Unit
- X/Y/Z axis travel
- 850/550/650mm
- Distance from column to spindle center
- 610mm
- Distance from table surface to spindle nose
- 125-775mm
Worktable
Unit
- Worktable size
- 550x1000mm
- T-slot size
- 5-18*100mm
- Max. load bearing of worktable
- 700kg
Spindle
Unit
- Spindle hole taper
- BT40
- Main motor power
- 11/15KW
- Spindle speed
- 8000(belt)rpm
Feed
Unit
- Max. feed speed
- 12000mm/min
- Rapid feed speed
- 12/12/12m/min
Tool magazine
Unit
- Tool magazine capacity
- 24T
- Tool change time
- 2.5S
Accuracy
Unit
- Positioning accuracy
- 0.01mm
- Re-positioning accuracy
- 0.005mm
Machine
Unit
- Machine dimension
- 2700*2510*3000mm
- Machine weight
- 6200kg
