SHL60BC-1200 High Capability Driven-Turret
- Model
- SHL60BC-1200
Item specifics
- Brand
- ZOPO Intelligent
- CNC
- Fanuc/Siemens/Mitsubishi/GNC/KND
- Spindle Hole Taper
- A2-6
- Control Mode
- Semi-closed loop
Review
Description
SHL60BC-1200
High Capability
Highly Integrated、High Accuracy
Φ610mm
Max.Swing Over Bed
1200mm
Max.Turning Length
Φ400mm
Max.Turning Dia
A2-6
Spindle Hole Taper
- Model
- Appearance
- Characteristic
- Parameters
- Contact Us
Appearance
Characteristic
Highly Integrated
Integrating turning and milling functions reduces the conversion of workpieces between different machines, improving processing efficiency and accuracy consistency
High Accuracy&Multi Axis Linkage
High accuracy machining: capable of processing parts with complex shapes and high-precision requirements, ensuring the dimensional accuracy, shape accuracy, and surface quality of the parts. It can be equipped with automatic tool changing systems, automatic loading and unloading devices, etc., to achieve highly automated production, reduce manual intervention, and improve production efficiency
Multi axis linkage: usually has multiple coordinate axes, which can achieve multi axis linkage machining and complete the machining of complex spatial surfaces and irregular structures
Parameters
Working Range
Unit
- Max. Swing Over Bed
- Φ610mm
- Max.Turning Length
- 120mm
- Max.Turning Dia
- Φ400mm
- Max. Swing Over Carriage
- Φ400mm
- X/Z Axis Travel
- 240/1210mm
Spindle
Unit
- Spindle Hole Taper
- A2-6
- Max. Passing Bar Dia.
- Φ50mm
- Spindle Speed Range
- 50-4500rpm
- Power
- 11/15kW
- Standard Chuck Dia.
- 8'' inch
Feed
Unit
- Rapid Feed Rate
- 30/30m/min
Tailstock
Unit
- Tailstock Spindle Taper
- 5#
Turret
Unit
- Standard Turret
- 12T（Driven）
- Nearby Tool Select
- Yes
Machine
Unit
- Machine Dimension
- 3800*1700*1865mm
- Machine Weight
- 5800kg
